Amazon.com: FullerKreg M6-1.0 x 16mm ISO 4762 Hex Drive Class 12.9 Black Oxide Finish Alloy Steel Socket Cap Screw (Pkg of 50): Home Improvement. ISO 4762:2004 specifies the characteristics of hexagon socket head cap screws with coarse pitch thread from M1,6 up to and including M64 and product grade A. ISO 4762 Hexagon socket Head Cap Screws Dimensions, Specifications, Standard, Weights, Equivalent and Download PDF.
Product Description. M20-2.5 Grade 14.9 DIN 912 ISO 4762 Screw Hexagon Socket Cap Bolt M20-2.5 Grade 14.9 DIN 912 cap bolt commonly used in machine parts, die fixturing, and clamping. The socket head enables driving where there is not sufficient space for wrenches or sockets. Provides custom made fasteners and customizable packaging. The symbol for the property classes of hex bolts, screws and studs consists of two numbers separated by a decimal point. 8.8, 10.9, 12.9, 14.9 etc. Take the whole number before the decimal point.
Iso 4762 Bolt
This number, when multiplied by a hundred, gives you the nominal tensile strength in newtons per millimetre squared. The digit following the decimal point, multiplied by ten, gives you the yield stress ration, or the percentage ratio between the lower yield stress and the nominal tensile strength. If you now multiply the first number by 10 times the second number you will arrive at the notional yield stress in newtons per millimetre squared. The main characteristic property of Nuts is the thread stripping strength (proof stress). The property classes of nuts are designated by a number which indicates the maximum appropriate property class of bolt with which they should be fitted. Therefore nut property classes are the same as the bolt designation initial number.
Bs En Iso 4762 Din 912 Hex File
Internationally, mechanical stress is expressed in newtons per square area, in bolting N/mm2. Common practise overseas is to use the unit megapascal (MPa), which corresponds directly to N/mm2.
